Action Capture with Accelerometers

Ronit Slyper and Jessica K. Hodgins

Carnegie Mellon University

We use accelerometers to do lookup into double-differentiated position-based motion capture data.

We create a performance animation system that leverages the power of low-cost accelerometers, readily available motion capture databases, and construction techniques from e-textiles. Our system, built with only off-the-shelf parts, consists of five accelerometers sewn into a comfortable shirt that streams data to a computer. The accelerometer readings are continuously matched against accelerations computed from existing motion capture data, and an avatar is animated with the closest match. We evaluate our system visually and using simultaneous motion and accelerometer capture.

Ronit Slyper and Jessica Hodgins. Action capture with Accelerometers. In 2008 ACM SIGGRAPH / Eurographics Symposium on Computer Animation, July 2008. BiBTeX

paper 4.8M
Keynote '08 presentation 88M. full movie is embedded
PowerPoint presentation (untested) 13M. contains movie clips
movie (mpeg4, compressed) 78M
diagrams A zipfile of the svg diagrams that went into the presentation
